Heavy-duty Caster with Frames C-1000 C-1000-750 MK

Since the wheel uses ductile cast iron (FCD-450), the strength is greatly increased compared to ordinary cast iron.For angle, for flat bar.(daN):294Allowable Weight (kgf):300Wheel Diameter (mm):75Wheel Width (mm):26Mounting Height H (mm):88.0Mounting Plate A x B (mm):120 x 37.0Mounting Pitch X (mm):94Mounting Hole Diameter P (mm):15 x 11Frame: SteelFrame Surface Treatment: Trivalent Chrome Plated FinishingWheel: Ductile Caste Iron (FCD-450)Allowable weight is a reference value in the vertical direction.
