Nail Anchor FNA2 44111 Fisher

Easy construction only requiring punching and driving with a hammer.For suspended ceilings, pipelines, cable ducts, wallboards, windows, fire prevention boards, etc.Nominal Designation of Thread:M6Total Length (mm):45Max Attachment Thickness (mm):5Drill Diameter (mm):6Standard Construction Torque (N\m):4Maximum Tensile Load (kN):1.4Max shear load(kN):1.4Effective buried depth(mm):25Pilot Hole Diameter (mm):6Buried Depth (mm):40Certified by the European Technical Approval(ETA)Packaged in a boxSteelSurface treatment: Zinc plated(trivalent chromate treatment)
