High Performance Anchor FH 2 44887 Fisher

Interaction between the body part of the screw and the sleeve enables high shear load.Construction is possible with a few number of anchors.For concrete and dense stone.Installation of various mounts.Equipment construction.Railing and exterior work, etc.Nominal Designation of Thread:M10Total Length (mm):106Width Across Flat (mm):17Max Attachment Thickness (mm):10Drill Diameter (mm):15Standard Construction Torque (N\m):40.0Maximum Tensile Load (kN):14.1Max shear load(kN):28.2Effective buried depth(mm):70European Technical Approval(ETA-07/0025)International Code Council CertificationHexagon head typePackaged in a boxSteelSurface treatment: Zinc plated(trivalent chromate treatment)
